Description

A work order comes in with a drawing: a machine foot, a bolt tray, a servo bracket. A block of aluminium sits in the vise and the tools for the job hang in the rack, a few of them tempting and wrong. Record the program one step at a time at the machine’s console, press CYCLE START and watch the cutter carve the block exactly as you told it to, chips flying.

The steps you record become real machine code, and the inspector measures the finished part against the drawing. A long cutter reaches deep but wobbles, a long drill wanders unless a spot drill seats it first, and a round cutter leaves its radius in every inside corner. The puzzle is in the plan.

Features

• Work orders: A drawing with its dimensions, a block in the vise and the tools for the job in the rack.
• Record the program: NEW STEP, a tool, an operation, tap the part, STORE: all at the machine’s console.
• CYCLE START: Your steps become real machine code, and the cutter carves the block exactly as told.
• Three stars: Passed inspection, inside the time goal and a clean finish. TRY AGAIN keeps your program.
• Apprentice and Machinist: The zero set for you and warnings before a run, or no warnings and the zero is yours.
• Playground: Draw your own part on the block, then machine it.

Gameplay

• The Perfect Part: gameplay (MP4, 1920x1080, 38 s, 7.0 MB)

Images

Click to download the full-size file.
